紧凑型CV DALI 30W
紧凑型CV DALI 30W
产品特性
纹波电流:±5%
调光范围: 1%-100%
调光方式:DALI-2
DALI功能: 走廊模式，应急模式，光衰补偿，Part251,252,253，Push Dim
保护种类: 开路/短路/过载/II类
启动时间:≤1S(DALI系统230VAC满载时)
工作温度:-25~45C
储存温度:-25~85°C
五年质保
认证:CE
应用: 线条灯
外壳尺寸: 30W: 135x36x25mm
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency （*Typical） |
Output Voltage |
No load Voltage |
|
CV30W24CG DALI |
0.375-1.25A |
≤0.19A |
≤34W |
9-30W |
≥0.92 |
89% |
24V |
23.5-24.5V |
|
CV30W48CG DALI |
0.18-0.625A |
≤0.19A |
≤34W |
90% |
48V |
47.5-48.5V |
