塑壳 DIP DALI DT6 21W
塑壳 DIP DALI DT6 21W
特性
输出类型：恒流
保护种类:短路/过载/空载
防护等级:IP20
启动时间:≤1S(230VAC，full load)
工作温度:-25~45℃
储存温度:-25~85℃
应用:面板灯
外壳尺寸:97.5*44*23mm (L*W*H)
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency |
Output Voltage |
No load Voltage |
|
C21C150-500D-D |
150mA |
0.05A |
9.8W |
2.25-6.75W |
0.75 |
80% |
15-45V |
59V Max |
|
200mA |
0.068A |
13.4W |
3-9W |
0.82 |
81% |
|||
|
250mA |
0.082A |
16.2W |
3.75-11.25W |
0.86 |
83% |
|||
|
300mA |
0.094A |
18.8W |
4.5-13.5W |
0.9 |
84% |
|||
|
350mA |
0.11A |
21.1W |
5.25-15.7W |
0.92 |
85% |
|||
|
400mA |
0.12A |
23.3W |
6-18W |
0.92 |
86% |
|||
|
450mA |
0.13A |
25.7W |
6.75-20.25W |
0.94 |
87% |
|||
|
500mA |
0.133A |
26.3W |
7.5-21W |
0.95 |
87% |
15-42V |
* Test result @230V, 50Hz, Full Load.
