四线导轨一体化电源DALI NFC 42W
四线导轨一体化电源DALI NFC 42W
特性
调光类型: DALI-2 / Push DIM
调光范围: DALI dimming: 1%- 100%
保护类型: 短路/过载/空载
防护等级: IP20
启动时间: ≤ 1s (230VAC)
工作温度: -25 ~ 35 ℃
储存温度: -40 ~ 75 ℃
应用: 轨道灯
外壳尺寸: 178*31.1*46mm (L*W*H)
参数规格
名称: T42C300-1050N-D-4W
系列: 导轨调光系列
调光方式: DALI-2 / Push DIM
功率: 42w: 300-1050mA
保修: 5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency (typ.)* |
Output Voltage |
No load Voltage |
|
T42C300-1050N-D-4W T42C300-1050N-D-4B T42C300-1050N-D-4G |
300mA |
0.10A |
15.00W |
3.00-12.60W |
0.86 |
84% |
10-42V |
59V |
|
350mA |
0.11A |
17.50W |
3.50-14.70W |
0.87 |
85% |
|||
|
400mA |
0.12A |
19.50W |
4.00-16.80W |
0.88 |
85% |
|||
|
450mA |
0.13A |
22.00W |
4.50-18.90W |
0.89 |
86% |
|||
|
500mA |
0.14A |
24.50W |
5.00-21.00W |
0.90 |
86% |
|||
|
550mA |
0.15A |
27.00W |
5.50-23.10W |
0.91 |
87% |
|||
|
600mA |
0.16A |
30.40W |
6.00-25.20W |
0.92 |
88% |
|||
|
650mA |
0.17A |
31.5W |
6.50-27.30W |
0.93 |
88% |
|||
|
700mA |
0.18A |
34.00W |
7.00-29.40W |
0.94 |
88% |
|||
|
750mA |
0.19A |
36.00W |
7.50-31.50W |
0.94 |
89% |
|||
|
800mA |
0.20A |
38.00W |
8.00-33.60W |
0.95 |
89% |
|||
|
850mA |
0.21A |
38.50W |
8.50-34.00W |
0.95 |
89% |
10-40V |
||
|
900mA |
0.22A |
40.5W |
9.00-36.00W |
0.96 |
89% |
|||
|
950mA |
0.23A |
43.00W |
9.50-38.00W |
0.96 |
90% |
|||
|
1000mA |
0.24A |
45.00W |
10.00-40.00W |
0.97 |
90% |
|||
|
1050mA |
0.24A |
47.20W |
10.50-42.00W |
0.97 |
90% |
