高效六线导轨DALI 40W
高效六线导轨DALI 40W
特性
纹波电流:±5%
调光方式:DALI-2
DALI功能: 光衰补偿,走廊模式,Part251.252.253,Push Dim
保护种类:空载/短路/过载/II类
启动时间:≤1S(DALI系统230VAC 满载时)
工作温度:-25~35℃
储存温度:-25~85°C
五年质保
认证:CE
应用:轨道灯
外壳尺寸: 198x31x45mm(LxWxH)
参数规格：
名称：
T40C250-1050D-D-6W
T40C250-1050D-D-6B
T40C250-1050D-D-6G
安装：独立式
调光方式：DALI-2
功率：
40W 250-1050mA
质保：5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency （*Typical） |
Output Voltage |
No load Voltage |
|
T40C250-1050D-D-6W T40C250-1050D-D-6B T40C250-1050D-D-6G |
250mA |
0.09A |
15.5W |
2.50-12.00W |
0.86 |
85% |
10-48V |
63V |
|
300mA |
0.11A |
18.5W |
3.00-14.40W |
0.86 |
85% |
10-48V |
63V |
|
|
350mA |
0.12A |
22.5W |
4.00-17.20W |
0.88 |
86% |
10-48V |
63V |
|
|
400mA |
0.13A |
23.5W |
4.00-19.20W |
0.88 |
87% |
10-48V |
63V |
|
|
450mA |
0.15A |
26.0W |
4.50-21.60W |
0.89 |
87% |
10-48V |
63V |
|
|
500mA |
0.17A |
29.00W |
5.00-24.00W |
0.90 |
87% |
10-48V |
63V |
|
|
550mA |
0.18A |
31.5W |
5.50-26.40W |
0.91 |
87% |
10-48V |
63V |
|
|
600mA |
0.19A |
34.0W |
6.00-28.80W |
0.92 |
89% |
10-48V |
63V |
|
|
650mA |
0.21A |
36.5W |
6.50-31.20W |
0.93 |
89% |
10-48V |
63V |
|
|
700mA |
0.22A |
39.0W |
7.00-33.60W |
0.94 |
90% |
10-48V |
63V |
|
|
750mA |
0.23A |
37.0W |
7.50-31.50W |
0.94 |
90% |
10-42V |
63V |
|
|
800mA |
0.24A |
40.5W |
8.00-33.6W |
0.95 |
90% |
10-42V |
63V |
|
|
850mA |
0.25A |
42W |
8.50-35.70W |
0.95 |
90% |
10-42V |
63V |
|
|
900mA |
0.25A |
44.0W |
9.00-37.80W |
0.96 |
90% |
10-42V |
63V |
|
|
950mA |
0.25A |
44.5W |
9.50-38.00W |
0.96 |
90% |
10-40V |
63V |
|
|
1050mA |
0.25A |
46.5W |
10.50-40.00W |
0.97 |
90% |
10-38V |
63V |
* Test result @230V, 50Hz, Full Load. Current setting
Categories：
恒定电流
导轨
产品中心
Keyword：
高效六线导轨DALI 40W
Kegu Power is ISO 9001:2015 certified and adopts Barcode Trace-abilitySystem for best quality control, and also has advanced ERP managementsystem to optimize the internal operation processes, and continuouslyenhance management performance and product competitiveness.Wealso Broad in external consultants and build fully automated productionline. Our products are engineered up to the utmost standard and passworldwide certificates such as CE,TUV,ENEC, CB, RoHS, UL and ccC ect.
