铁壳隔离 DALI SELV 35W/50W/75W
铁壳隔离 DALI SELV 35W/50W/75W
特性
纹波电流：＜3%
调光方式：DALI-2
DALI功能：走廊模式，应急模式，光衰补偿，Part251.252.253，Push Dim
保护种类：空载/短路/过载/I类/隔离
启动时间：≤1S（DALI系统230VAC满载时）
工作温度：-25~50℃
储存温度：-25~85℃
认证：CE
应用：线条灯，三防灯
外壳尺寸：280*30*21mm（L*W*H）
参数规格
名称：
L35C150-700D-D
L50C300-1050D-D
L75C900-1800D-D
安装：内置
功率：
35W 150-700mA
50W 300-1050mA
75W 900-1800mA
质保：5年
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model 型号 |
Output Current 输出电流 |
Input Current 输入电流 |
Input Power 输入功率 |
Output Power Range 输出功率范围 |
PF 功率因数 |
Efficiency （*Typical） 效率 （典型值） |
Output Voltage 输出电压 |
No load Voltage 空载电压 |
|
L35C150-700D-D |
150mA |
0.11A |
12W |
3-7.5W |
0.75 |
79% |
20-50V |
63V Max. |
|
200mA |
0.12A |
13W |
4-10W |
0.8 |
82% |
|||
|
250mA |
0.13A |
16W |
5-12.5W |
0.82 |
84% |
|||
|
300mA |
0.14A |
19W |
6-15W |
0.83 |
86% |
|||
|
350mA |
0.15A |
22W |
7-17.5W |
0.85 |
87% |
|||
|
400mA |
0.16A |
25W |
8-20W |
0.91 |
87% |
|||
|
450mA |
0.17A |
27W |
9-22.5W |
0.92 |
88% |
|||
|
500mA |
0.18A |
30W |
10-25W |
0.94 |
88% |
|||
|
550mA |
0.19A |
32W |
11-27.5W |
0.94 |
88% |
|||
|
600mA |
0.20A |
35W |
12-30W |
0.95 |
89% |
|||
|
650mA |
0.21A |
37W |
13-32.50W |
0.95 |
89% |
|||
|
700mA |
0.22A |
40W |
14-35W |
0.95 |
89% |
|||
|
L50C300-1050D-D |
300mA |
0.11A |
20W |
6-15W |
0.89 |
86% |
20-50V |
63V Max. |
|
350mA |
0.12A |
22W |
7-17.5W |
0.89 |
86% |
|||
|
400mA |
0.14A |
25W |
8-20W |
0.89 |
87% |
|||
|
450mA |
0.15A |
28W |
9-22.5W |
0.89 |
87% |
|||
|
500mA |
0.16A |
30W |
10-25W |
0.90 |
87% |
|||
|
550mA |
0.18A |
33W |
11-27.5W |
0.90 |
87% |
|||
|
600mA |
0.19A |
36W |
12-30W |
0.91 |
88% |
|||
|
650mA |
0.21A |
38W |
13-32.5W |
0.92 |
89% |
|||
|
700mA |
0.22A |
42W |
14-35W |
0.92 |
89% |
|||
|
750mA |
0.23A |
44W |
15-37.5W |
0.93 |
89% |
|||
|
800mA |
0.25A |
47W |
16-40W |
0.93 |
89% |
|||
|
850mA |
0.27A |
50W |
17-42.5W |
0.94 |
89% |
|||
|
900mA |
0.28A |
52W |
18-45W |
0.94 |
89% |
|||
|
950mA |
0.29A |
55W |
19-47.5W |
0.95 |
89% |
|||
|
1000mA |
0.31A |
58W |
20-50W |
0.95 |
89% |
|||
|
1050mA |
0.32A |
62W |
21-52.5W |
0.95 |
89% |
|||
|
L75C900-1800D-D |
900mA |
0.28A |
52.0W |
18-45W |
0.92 |
87% |
20-50V |
63V Max. |
|
1000mA |
0.29A |
58.0W |
20-50W |
0.93 |
88% |
|||
|
1100mA |
0.31A |
63.0W |
22-55W |
0.93 |
89% |
|||
|
1200mA |
0.33A |
69.0W |
24-60W |
0.94 |
89% |
|||
|
1300mA |
0.35A |
74.0W |
26-65W |
0.94 |
90% |
|||
|
1400mA |
0.37A |
79.0W |
28-70W |
0.95 |
91% |
|||
|
1500mA |
0.39A |
85.0W |
30-75W |
0.95 |
91% |
|||
|
1600mA |
0.41A |
77.0W |
32-67.2W |
0.94 |
90% |
20-42V |
||
|
1700mA |
0.43A |
81.0W |
34-71.4W |
0.95 |
90% |
|||
|
1800mA |
0.45A |
85.0W |
36-75.6W |
0.95 |
90% |
* Test result @230V, 50Hz, Full Load. 230V，50Hz，满载
