IP67 DALI NFC 15W 23W 44W 70W
IP67 DALI NFC 15W 23W 44W 70W
特性
电流精度：±5%
保护种类:短路/过载/空载
防护等级:IP67
工作温度:-25~50℃
存储温度:-40~85℃
认证:CE
应用：路灯，泛光灯
外壳尺寸:15W,23W：103*47*26mm (L*W*H)
44W：110*52*28.5mm (L*W*H)
70W：109*69.5*32.5mm (L*W*H)
参数规格
名称:
XC15W100-500 DALI NFC
XC23W100-700 DALI NFC
XC44W300-1050 DALI NFC
XC70W350-1400 DALI NFC
安装：内置和独立式
调光类型：DALI-2
功率:
15W 100-500mA
23W 100-700mA
44W 300-1050mA
70W 350-1400mA
质保期: 5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency |
Output Voltage |
No load Voltage |
|
XC15W100-500 DALI NFC |
100-500mA |
≤0.10A |
19W |
0.25-15.05W |
≥0.95 |
≥84.5% |
2.5-46V |
59V |
|
XC23W100-700 DALI NFC |
100-700mA |
≤0.14A |
27W |
0.25-23.00W |
≥0.95 |
≥86.5% |
2.5-46V |
59V |
|
XC44W300-1050 DALI NFC |
300-1050mA |
≤0.26A |
51W |
2.70-44.10W |
≥0.95 |
≥89% |
9.0-49V |
59V |
|
XC70W350-1400 DALI NFC |
350-1400mA |
≤0.40A |
78W |
3.50-70.00W |
≥0.95 |
≥89% |
10-50V |
59V |
* Test result @230V, 50Hz, Full Load. Current setting@1mA-steps(NFC)
