IP67 NFC 15W 23W 44W 70W
IP67 NFC 15W 23W 44W 70W
特性
电流精度：±5%
保护种类:短路/过载/空载
防护等级:IP67
工作温度:-25~50℃
存储温度:-40~85℃
认证:CE
应用：路灯，泛光灯
外壳尺寸:15W,23W：103*47*26mm (L*W*H)
44W：110*52*28.5mm (L*W*H)
70W：109*69.5*32.5mm (L*W*H)
参数规格
名称:
XC15W100-500 NFC
XC23W100-700 NFC
XC70W350-1400 NFC
安装：内置和独立式
功率:
15W 100-500mA
23W 100-700mA
44W 300-1050mA
70W 350-1400mA
质保期: 5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model 型号 |
Output Current 输出电流 |
Input Current 输入电流 |
Input Power 输入功率 |
Output Power Range 输出功率范围 |
PF 功率 因数 |
Efficiency （*Typical） 效率 （典型值） |
Output Voltage 输出电压 |
No load Voltage 空载电压 |
|
X15C100-500N-N |
100-500mA |
≤0.10A |
19W |
0.25-15.05W |
≥0.95 |
≥86% |
2.5-46V |
59V |
|
X23C100-700N-N |
100-700mA |
≤0.14A |
27W |
0.25-23.00W |
≥0.95 |
≥86% |
2.5-46V |
59V |
|
X44C300-1050N-N |
300-1050mA |
≤0.26A |
51W |
2.70-44.10W |
≥0.95 |
≥89% |
9.0-49V |
59V |
|
X70C350-1400N-N |
350-1400mA |
≤0.40A |
78W |
3.50-70.00W |
≥0.95 |
≥89.5% |
10-50V |
59V |
* Test result @230V, 50Hz, Full Load. 所有测试参数基于@230V, 50Hz, 满载
