非隔离 DALI 35W 60W 100W
非隔离 DALI 35W 60W 100W
特性
电流精度：±5%
电流波纹：±5%
保护种类:短路/过载
防护等级:IP20
工作温度:-25~60℃
存储温度:-35~85℃
认证:CE
应用：三防灯，线条灯
外壳尺寸:280*30*21mm (L*W*H)
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model 型号 |
Output Current 输出电流 |
Input Current 输入电流 |
Input Power 输入功率 |
Output Power Range 输出功率范围 |
PF 功率因数 |
Efficiency （*Typical） 效率 （典型值） |
Output Voltage 输出电压 |
No load Voltage 空载电压 |
|
L35C75-400N-D |
75-400mA |
0.21A |
42W |
3.75-35W |
0.95 |
93% |
50-240V |
300V |
|
L60C120-550N-D |
120-550mA |
0.33A |
68W |
6-60W |
0.95 |
94% |
50-240V |
300V |
|
L100C250-1050N-D |
250-1050mA |
0.62A |
108W |
12.5-100.0W |
0.95 |
95% |
50-240V |
300V |
