隐藏式导轨 DALI 30W
隐藏式导轨 DALI 30W
特性
调光类型: DALI-2 / PUSH Dimming
调光范围：0.1%-100%
保护类型: 短路/过载/空载
防护等级: IP20
启动时间: ＜ 0.5s
工作温度: -20 ~ 35 ℃
储存温度: -35 ~ 75 ℃
应用: 轨道灯
外壳尺寸: 308*28*25.3mm (L*W*H)
参数规格
名称: T30C150-700D-D-6W
系列: 隐藏式导轨电源系列
调光方式: DALI-2 / PUSH Dimming
功率: 30w: 150-700mA
质保期: 5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current（*Typical） |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency（*Typical） |
Output Voltage |
No load Voltage |
|
T30C150-700D-D-6W T30C150-700D-D-6B T30C150-700D-D-6G |
150mA |
0.10A |
8.07W |
1.50-6.30W |
0.75 |
83% |
10-42V |
59V |
|
200mA |
0.11A |
10.5W |
2.00-8.40W |
0.8 |
85% |
10-42V |
59V |
|
|
250mA |
0.12A |
12.8W |
2.50-10.50W |
0.82 |
86% |
10-42V |
59V |
|
|
300mA |
0.13A |
15.3W |
3.00-12.60W |
0.83 |
88% |
10-42V |
59V |
|
|
350mA |
0.14A |
17.7W |
3.50-14.70W |
0.85 |
88% |
10-42V |
59V |
|
|
400mA |
0.15A |
20W |
4.00-16.80W |
0.91 |
89% |
10-42V |
59V |
|
|
450mA |
0.16A |
22.5W |
4.50-18.90W |
0.92 |
89% |
10-42V |
59V |
|
|
500mA |
0.17A |
25W |
5.00-21.00W |
0.94 |
89% |
10-42V |
59V |
|
|
550mA |
0.18A |
27.5W |
5.50-23.10W |
0.94 |
89% |
10-42V |
59V |
|
|
600mA |
0.19A |
29.6W |
6.00-25.20W |
0.95 |
89% |
10-42V |
59V |
|
|
650mA |
0.20A |
32.1W |
6.50-27.30W |
0.95 |
89% |
10-42V |
59V |
|
|
700mA |
0.21A |
34.4W |
7.00-29.40W |
0.95 |
89% |
10-42V |
59V |
