智能导轨一体化双路调光电源 42W
智能导轨一体化双路调光电源 42W
特性
调光类型: Casambi
保护类型: 短路/过载/空载
防护等级: IP20
启动时间: ≤ 0.5s (230VAC)
工作温度: -25 ~ 35 ℃
储存温度: -30 ~ 85 ℃
应用: 轨道灯
外壳尺寸: 220*31*45mm (L*W*H)
参数规格
名称: T42C300-1050N-2X-4W
系列: 可插拔双路调光系列
调光方式: Casambi
功率: 42w: 300-1050mA
保修: 5年
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current（*Typical） |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency |
Output Voltage |
No load Voltage |
|
T42C300-1050N-2X-4W
T42C300-1050N-2X-4B
T42C300-1050N-2X-4G |
300mA |
0.07A |
15.4W |
3.00-12.60W |
0.86 |
85% |
10-42V |
59V |
|
350mA |
0.08A |
17.9W |
3.50-14.70W |
0.87 |
86% |
10-42V |
59V |
|
|
400mA |
0.09A |
20.5W |
4.00-16.80W |
0.88 |
87% |
10-42V |
59V |
|
|
450mA |
0.10A |
22.8W |
4.50-18.90W |
0.89 |
87% |
10-42V |
59V |
|
|
500mA |
0.11A |
25.3W |
5.00-21.00W |
0.90 |
87% |
10-42V |
59V |
|
|
550mA |
0.12A |
27.8W |
5.50-23.10W |
0.91 |
87% |
10-42V |
59V |
|
|
600mA |
0.14A |
30.4W |
6.00-25.20W |
0.92 |
89% |
10-42V |
59V |
|
|
650mA |
0.15A |
32.5W |
6.50-27.30W |
0.93 |
89% |
10-42V |
59V |
|
|
700mA |
0.16A |
35W |
7.00-29.40W |
0.94 |
90% |
10-42V |
59V |
|
|
750mA |
0.17A |
37.5W |
7.50-31.50W |
0.94 |
90% |
10-42V |
59V |
|
|
800mA |
0.18A |
40W |
8.00-33.60W |
0.95 |
90% |
10-42V |
59V |
|
|
850mA |
0.18A |
40W |
8.50-34.00W |
0.95 |
90% |
10-40V |
59V |
|
|
900mA |
0.2A |
42.4W |
9.00-36.00W |
0.96 |
90% |
10-40V |
59V |
|
|
950mA |
0.2A |
44.7W |
9.50-38.00W |
0.96 |
90% |
10-40V |
59V |
|
|
1000mA |
0.23A |
46.5W |
10.00-40.00W |
0.97 |
90% |
10-40V |
59V |
|
|
1050mA |
0.24A |
48.8W |
10.50-42.00W |
0.97 |
90% |
10-40V |
59V |
