塑壳 DIP DALI DT6 30W
塑壳 DIP DALI DT6 30W
特性
输出类型：恒流
保护种类:短路/过载/空载
防护等级:IP20
启动时间:≤1S(230VAC，full load)
工作温度:-25~45℃
储存温度:-25~85℃
应用:面板灯
外壳尺寸:97*44*23mm (L*W*H)
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency |
Output Voltage |
No load Voltage |
|
C30C350-700D-D |
350mA |
0.1A |
20W |
3.15-15.75W |
0.88 |
84% |
9-45V |
59V Max |
|
400mA |
0.113A |
22.5W |
3.6-18W |
0.9 |
84% |
|||
|
450mA |
0.126A |
25W |
4.05-20.25W |
0.92 |
85% |
|||
|
500mA |
0.135A |
27.8W |
4.5-22.5W |
0.92 |
86% |
|||
|
550mA |
0.15A |
30.5W |
4.95-24.75W |
0.94 |
86% |
|||
|
600mA |
0.16A |
32.5W |
5.4-27W |
0.94 |
87% |
|||
|
650mA |
0.167A |
35W |
5.85-29.25W |
0.95 |
87% |
|||
|
700mA |
0.18A |
37.5W |
6.3-31.5W |
0.95 |
88% |
