紧凑型 DALI NFC DT6 80W
紧凑型 DALI NFC DT6 80W
特性
调光类型：DALI-2 / Push DIM
调光范围：DALI 调光 1%-100%
保护种类:短路/过载/空载
防护等级:IP20
启动时间:≤1S(230VAC，full load)
工作温度:-25~50℃
储存温度:-25~85℃
应用:面板灯
外壳尺寸:157.8*56*30mm (L*W*H)
File Download：
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current（*Typical） |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency (typ.)* |
Output Voltage |
No load Voltage |
|
C80C1200-2100N-D |
1200mA |
0.37A |
71W |
3-62.4W |
≥0.95 |
90% |
2.5-52V |
70V Max. |
|
1250mA |
0.38A |
74W |
3.13-65W |
90% |
||||
|
1300mA |
0.40A |
77W |
3.25-67.6W |
90% |
||||
|
1350mA |
0.41A |
80W |
3.38-70.2W |
90% |
||||
|
1400mA |
0.43A |
83W |
3.5-72.8W |
90% |
||||
|
1450mA |
0.44A |
86W |
3.63-75.4W |
90% |
||||
|
1500mA |
≤0.47A |
91W |
3.75-78W |
90% |
||||
|
1550mA |
3.875-80.6W |
90% |
||||||
|
1600mA |
4-80W |
90% |
||||||
|
1650mA |
4.12-79.2W |
90% |
||||||
|
1700mA |
4.25-79.9W |
90% |
2.5-50V |
|||||
|
1750mA |
4.375-80.5W |
90% |
2.5-48V |
|||||
|
1800mA |
4.5-79.2W |
90% |
2.5-46V |
|||||
|
1850mA |
4.625-79.55W |
90% |
2.5-44V |
|||||
|
1900mA |
4.75-79.8W |
90% |
2.5-43V |
|||||
|
1950mA |
4.875-79.95W |
90% |
2.5-42V |
|||||
|
2000mA |
5-80W |
90% |
2.5-40V |
|||||
|
2050mA |
5.125-79.95W |
90% |
2.5-39V |
|||||
|
2100mA |
5.25-79.8W |
90% |
2.5-38V |
* Test result @230V, 50Hz, Full Load.Current setting @ 1mA-steps (NFC)
