超薄非隔离铁壳DALI NFC 35W 75W
超薄非隔离铁壳DALI NFC 35W 75W
特性
纹波电流:±5%
保护种类:短路/空载/过载
防护等级:IP20
启动时间:≤1S
工作温度:-20~55℃
存储温度:-30~85℃
认证:CE
应用:三防灯，线条灯
外壳尺寸:360*30*11mm (L*W*H)
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model 型号 |
Output Current 输出电流 |
Input Current 输入电流 |
Input Power 输入功率 |
Output Power Range 输出功率范围 |
PF 功率因数 |
Efficiency （*Typical） 效率 （典型值） |
Output Voltage 输出电压 |
No load Voltage 空载电压 |
|
L35C75-400N-D-F |
75-400mA |
0.19A |
42W |
4-35W |
0.95 |
93.5% |
54-240V |
300V |
|
L75C150-700N-D-F |
150-700mA |
0.36A |
81W |
8.1-75W |
0.95 |
94.5% |
54-240V |
300V |
* Test result @230V, 50Hz, Full Load. Current setting @ 1mA-steps (NFC)
230V，50Hz，满载。当前设置@1mA步数（NFC）
