紧凑型恒流内外置式 15W 23W 36W
紧凑型恒流内外置式 15W 23W 36W
特性
NFC电流调节
特殊: EL应急模式、走廊模式
保护类型: 短路/过载/空载/II级
防护等级: IP20
启动时间: ≤ 0.7s/230VAC
工作温度: -20 ~ 50 ℃
储存温度: -20 ~ 85 ℃
认证: CE
应用: 面板灯，管灯
外壳尺寸:
138.7*31 * 21.5毫米 (L * W * H) 独立 @ 15w & 23w
118.7*31 * 21.5毫米 (L * W * H) 内置 @ 15w & 23w
163.7*31 * 21.5毫米 (L * W * H) 独立 @ 36w
143.7*31 * 21.5毫米 (L * W * H) 内置 @ 36w
参数规格
名称:
S15C100-350N-N
S23C100-700N-N
S36C150-900N-N
系列: 超薄非调光系列
电流:
15W：100-350mA
23W：100-700mA
36W：150-900mA
质保:5年
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency （*Typical） |
Output Voltage |
No load Voltage |
|
S15C100-350N-N |
100mA |
0.035A |
5.8W |
0.25-4.6W |
0.74 |
77% |
2.5-46V |
59V |
|
150mA |
0.045A |
8.4W |
0.37-6.9W |
0.83 |
80% |
2.5-46V |
59V |
|
|
200mA |
0.054A |
10.9W |
0.5-9.2W |
0.89 |
82% |
2.5-46V |
59V |
|
|
250mA |
0.064A |
13.4W |
0.62-11.5W |
0.92 |
84% |
2.5-46V |
59V |
|
|
300mA |
0.074A |
16.0W |
0.75-13.8W |
0.93 |
85% |
2.5-46V |
59V |
|
|
350mA |
0.082A |
18.4W |
0.87-15W |
0.94 |
85% |
2.5-43V |
59V |
|
|
S23C100-700N-N |
100mA |
0.035A |
5.8W |
0.25-4.6W |
0.74 |
77% |
2.5-46V |
59V |
|
150mA |
0.045A |
8.4W |
0.37-6.9W |
0.83 |
80% |
2.5-46V |
59V |
|
|
200mA |
0.054A |
10.9W |
0.50-9.2W |
0.89 |
82% |
2.5-46V |
59V |
|
|
250mA |
0.064A |
13.4W |
0.62-11.5W |
0.92 |
84% |
2.5-46V |
59V |
|
|
300mA |
0.074A |
16.0W |
0.75-13.8W |
0.94 |
86% |
2.5-46V |
59V |
|
|
350mA |
0.082A |
18.4W |
0.87-16.1W |
0.96 |
86% |
2.5-46V |
59V |
|
|
400mA |
0.095A |
20.9W |
1.00-18.4W |
0.97 |
87% |
2.5-46V |
59V |
|
|
450mA |
0.106A |
23.5W |
1.12-20.7W |
0.97 |
87% |
2.5-46V |
59V |
|
|
500mA |
0.116A |
26W |
1.25-23.0W |
0.98 |
88% |
2.5-46V |
59V |
|
|
550mA |
0.093A |
20.5W |
1.37-22.5W |
0.97 |
86% |
2.5-41V |
59V |
|
|
600mA |
0.10A |
22.2W |
1.50-22.8W |
0.97 |
86% |
2.5-38V |
59V |
|
|
650mA |
0.108A |
24.1W |
1.62-22.7W |
0.98 |
86% |
2.5-35V |
59V |
|
|
700mA |
0.114A |
25.7W |
1.75-22.4W |
0.98 |
86% |
2.5-32V |
59V |
|
|
S36C150-900N-N |
150mA |
0.055A |
9.52W |
0.37-7.5W |
0.76 |
79% |
2.5-50V |
65V |
|
200mA |
0.063A |
12.05W |
0.5-10W |
0.83 |
82% |
2.5-50V |
65V |
|
|
250mA |
0.075A |
14.96W |
0.62-12.5W |
0.87 |
83% |
2.5-50V |
65V |
|
|
300mA |
0.086A |
17.67W |
0.75-15.0W |
0.89 |
84% |
2.5-50V |
65V |
|
|
350mA |
0.098A |
20.37W |
0.87-17.5W |
0.91 |
85% |
2.5-50V |
65V |
|
|
400mA |
0.108A |
22.99W |
1.0-20.0W |
0.94 |
86% |
2.5-50V |
65V |
|
|
450mA |
0.120A |
25.83W |
1.1-22.5W |
0.94 |
86% |
2.5-50V |
65V |
|
|
500mA |
0.132A |
28.69W |
1.2-25W |
0.95 |
86% |
2.5-50V |
65V |
|
|
550mA |
0.143A |
31.36W |
1.3-27.5W |
0.96 |
87% |
2.5-50V |
65V |
|
|
600mA |
0.154A |
34.08W |
1.5-30W |
0.96 |
87% |
2.5-50V |
65V |
|
|
650mA |
0.166A |
36.92W |
1.6-32.5W |
0.97 |
87% |
2.5-50V |
65V |
|
|
700mA |
0.178A |
39.69W |
1.7-35W |
0.97 |
87% |
2.5-50V |
65V |
|
|
750mA |
0.183A |
40.96W |
1.8-36W |
0.97 |
88% |
2.5-48V |
65V |
|
|
800mA |
0.192A |
43.13W |
2.0-36W |
0.97 |
88% |
2.5-45V |
65V |
|
|
850mA |
0.186A |
41.57W |
2.1-35.7W |
0.98 |
88% |
2.5-42V |
65V |
|
|
900mA |
0.193A |
43.24W |
2.2-36W |
0.97 |
88% |
2.5-40V |
65V |
