Tiny NFC Casambi 10W 15W
Tiny NFC Casambi 10W 15W
特性
调光类型：CASAMBI
当前设置：NFC
NFC调电流
保护种类:短路/过载/空载/Ⅱ类
防护等级:IP20
启动时间:≤1S(230VAC，full load)
工作温度:-20~50℃
储存温度:-35~85℃
应用:筒灯、面板灯
外壳尺寸:64.5*40*23mm (L*W*H)
参数规格
名称:
C10C150-500N-C
C15C100-700N-C
NFC调电流
功率：
10W:150-500mA
15W:100-700mA
质保期:5年
Phone:
+86-757-6682 2764
Email:
info@kg-power.com
Enquire Now
PRODUCT DESCRIPTION
|
Model |
Output Current |
Input Current |
Input Power |
Output Power Range |
PF |
Efficiency （*Typical） |
Output Voltage |
No load Voltage |
|
CC10W150-500 CAB NFC-1 |
150mA |
0.05A |
8.8W |
0.38-6.75W |
0.75 |
84% |
2.5-45V |
59V |
|
200mA |
0.07A |
11.5W |
0.50-9.00W |
0.85 |
85% |
2.5-45V |
59V |
|
|
250mA |
0.07A |
12.8W |
0.63-10.00W |
0.88 |
85% |
2.5-40V |
59V |
|
|
300mA |
0.07A |
12.5W |
0.75-9.90W |
0.88 |
84% |
2.5-33V |
59V |
|
|
350mA |
0.07A |
12.5W |
0.88-9.80W |
0.88 |
84% |
2.5-28V |
59V |
|
|
400mA |
0.07A |
12.6W |
1.00-10.00W |
0.88 |
84% |
2.5-25V |
59V |
|
|
450mA |
0.07A |
11.5W |
1.13-9.00W |
0.88 |
84% |
2.5-20V |
59V |
|
|
500mA |
0.07A |
12.6W |
1.25-10.00W |
0.88 |
84% |
2.5-20V |
59V |
|
|
CC15W100-700 CAB NFC-1 |
100mA |
0.04A |
6.5W |
0.25-4.50W |
0.6 |
83% |
2.5-45V |
59V |
|
200mA |
0.07A |
11.5W |
0.50-9.00W |
0.8 |
85% |
2.5-45V |
59V |
|
|
300mA |
0.10A |
16.8W |
0.75-13.50W |
0.85 |
86% |
2.5-45V |
59V |
|
|
400mA |
0.11A |
18.8W |
1.00-15.20W |
0.92 |
85% |
2.5-38V |
59V |
|
|
500mA |
0.11A |
18.6W |
1.25-15.00W |
0.92 |
85% |
2.5-30V |
59V |
|
|
600mA |
0.11A |
18.5W |
1.50-15.00W |
0.92 |
85% |
2.5-25V |
59V |
|
|
700mA |
0.11A |
19.0W |
1.75-15.4W |
0.92 |
85% |
2.5-22V |
59V |
